ESB Audio 3.10D2 subwoofer - 10", 300W RMS, 2x2 Ohm, 29Hz

ESB Audio 3.10D2 car subwoofer

This ESB subwoofer is a precision speaker designed to provide extremely high-quality sub-frequency performance in a car. To maximize the performance of this subwoofer, we strongly recommend using a custom enclosure.

Enclosure recommendation

The subwoofer is suitable for both sealed and ported enclosures.

BASS REFLEX ENCLOSURE 2 (recommended)
Net volume:
3.10D4/D2: 21 liters (0.74 ft³)
External dimensions:
3.10D4/D2: 386 × 320 × 260 mm
Port dimensions:
3.10D4/D2: Ø56 × 300 mm
Panels:
Top/bottom (2 pcs): 386 × 260 mm
Front/back (2 pcs): 386 × 284 mm
Left/right sides (2 pcs): 284 × 224 mm
Wall thickness: 18 mm. Thinner material can reduce the rigidity of the enclosure and cause leaks. Add damping material to approx. 35% of the volume.

BASS REFLEX ENCLOSURE 3 (recommended)
Net volume:
3.10D4/D2: 28 liters (0.99 ft³)
External dimensions:
3.10D4/D2: 471 × 320 × 260/160 mm
Port dimensions:
3.10D4/D2: Ø56 × 300 mm
Panels:
Top (1 pc): 471 × 166* mm
Bottom (1 pc): 471 × 260* mm
Front (1 pc): 471 × 284 mm
Back (1 pc): 471 × 298* mm
Left/right sides (2 pcs): 284 × 217 mm
*Angled side
Wall thickness: 18 mm. Thinner material can reduce the rigidity of the enclosure and cause leaks. Add damping material to approx. 35% of the volume.
