SounDigital 8000.1 EVO5 1 Ohm

Soundigital amplifiers take the power/price/size ratio of amplifiers to a new level. Never before has such high power been achieved from such small external dimensions. And at a very reasonable price!

All models have a damping factor of over 1000! High power consumption consumes a lot of power, and in many cars, voltage drops at the peak of the music and when playing loudly are a problem.

Soundigital's amplifiers take this practical situation into account so that the operating voltage of the amplifiers can be as low as 9 volts! Soundigital operates in a very rare way as an amplifier manufacturer today, ALL models are designed and manufactured in their own production facility in Brazil.

Compatible with SD-RLC Remote level control.

Power @ 4Ω: 1 X 3844 WRMS
Power @ 2Ω: 1 X 5360 WRMS
Power @ 1Ω: 1 X 8000 WRMS

Frequency Response (-3dB):

8Hz ~ 20kHz

Subsonic (12dB/oct):

8Hz ~ 80Hz

Low Pass filter (12dB/oct):

50Hz ~ 20kHz

Bass Boost:

0dB ~ 12dB @ 50Hz

Operating Voltage:

9V~16V

SNR

@ 1Ω: 92dB
@ 2Ω: 85dB

Input Sensitivity (RCA):

0.2V ~ 2V

Input Sensitivity (High Level input):

1.3V ~ 15V

Current Draw (music):

381A

Current Draw (max.)

762A

Total Efficiency:

80%

Damping Factor (@100Hz nominal impedance)

10000

Power Cable:

70mm² (00 AWG)

Speaker Cable

2 x 10mm² (7AWG)

Recommended Fuse (music):

2x200A

Recommended battery (minimum):

2 x 220Ah

Width:

7.1″ / 18 cm

Length:

12.2″ / 31 cm

Height:

2.5″ / 6.32 cm

Weight:

8.79 lbs / 3.99 kg

Do not connect the amplifier to less than the rated load!

Do not run your amp under rated impedance!.
