SoundDigital's EVO 6 is the world's smallest amplifier series in these power classes, making it the right choice when size and power matter!
Despite the amplifier's small size, the output power is up to 800 W RMS!
This is not just an amplifier — the EVO6 is also a major step in audio evolution. An amplifier with high efficiency that, due to its size, fits anywhere.
Artificial intelligence has been used in the design of the EVO6 series — welcome to a journey into the future!
Technical Specifications
- Output Power (CH1–4): 4 × 100 W RMS @ 4 Ω / 4 × 66 W RMS @ 8 Ω
- Bridged: 2 × 200 W RMS @ 8 Ω
- Sub (CH5): 1 × 400 W RMS @ 4 Ω
- Operating Voltage: 9–16 V
- Current Consumption (music): 39 A
- Current Consumption (max): 78.7 A
- Recommended Fuse: 40 A / Recommended Battery (minimum): 60 Ah
- Efficiency: 80 %
- Damping Factor: 200 (@ 100 Hz)
- Frequency Response CH1–4: 80 Hz–25 kHz
- Frequency Response sub: 5–80 Hz
- SNR: 103.9 dB (CH1–4) / 102 dB (sub)
- Crossover HPF/LPF: 80 Hz (12 dB/oct)
- Input Sensitivity (RCA): 0.2–2 V
- Power Cable: 10 mm² (7 AWG)
- Speaker Cable: 1.5 mm² (15 AWG) / 2.5 mm² (13 AWG)
- Dimensions (L × W × H): 117 × 157 × 55 mm
- Weight: 0.74 kg
Do not connect the amplifier below the rated load!
