SounDigital 5000.1 EVO 5 – 1-channel amplifier 2 Ω

The SounDigital 5000.1 EVO 5 takes amplifiers' power/price/size ratio to a new level. Never before has such large power been extracted from such small external dimensions – and at a very reasonable price. Damping factor 2000, operating voltage already from 8 volts. All SounDigital models are designed and manufactured in their own production facility in Brazil.

Specifications

• Output Power: 1 × 5000 W @ 2 Ω / 1 × 3300 W @ 4 Ω
• Operating Voltage: 8–16 V
• Current Consumption (Music): 230 A
• Current Consumption (Max): 461 A
• Recommended Fuse: 250 A
• Recommended Battery: 250 Ah
• Power Cable: 50 mm² (0 AWG)
• Speaker Cable: 2 × 10 mm² (7 AWG)
• Efficiency: 86 %
• Damping Factor: 2000
• Frequency Response: 5 Hz–6 kHz
• SNR: 90 dB
• Input Sensitivity (RCA): 0.2–2 V
• Input Sensitivity (High Level): 1.2–12 V
• Subsonic Filter: 5–80 Hz
• Low Pass Filter (LPF): 50 Hz–6 kHz
• Dimensions (L × W × H): 250 × 180 × 63 mm
• Weight: 2.75 kg

Do not connect the amplifier below the rated load!
