SounDigital amplifiers take the power/price/size ratio of amplifiers to a new level. Never before have such high powers been extracted from such small external dimensions - and at a very reasonable price!
Key Features
- Damping Factor over 1000 - Excellent bass control
- Operates at voltages as low as 9V - No problems with voltage drop
- Brazilian Quality - All models designed and manufactured in their own production facility
- Compact Size - Easy to install
Technical Specifications
Power
- 1 Ω: 5000 W RMS
- 2 Ω: 3300 W RMS
- 4 Ω: 2178 W RMS
Frequency Response and Filters
- Frequency Response (-3dB): 5 Hz - 6 kHz
- Low Pass Filter (12dB/oct): 50 Hz - 6 kHz
- Subsonic (12dB/oct): 5 Hz - 80 Hz
Electrical Specifications
- Operating Voltage: 8-16 V
- Signal-to-Noise Ratio: 90 dB
- Current Consumption (music): 230 A
- Current Consumption (max): 461 A
- Efficiency: 86%
- Damping Factor (@100Hz): 2000
Connections and Sensitivity
- RCA Input: 0.2-2 V
- High Level Input: 1.2-12 V
- Power Cable: 50 mm² (0 AWG)
- Speaker Cable: 2 x 10 mm² (7 AWG)
- Recommended Fuse: 250 A
- Recommended Battery (min): 250 Ah
Dimensions and Weight
- Width: 18 cm (7.1")
- Length: 25 cm (9.9")
- Height: 6.3 cm (2.5")
- Weight: 2.75 kg (6.06 lb)
