The SounDigital 1200.1 EVO 5 takes amplifiers' power/price/size ratio to a new level. Never before have such high power outputs been achieved from such small external dimensions – and at a very reasonable price. Damping factor 2000, operating voltage from as low as 9 volts. All SounDigital models are designed and manufactured in their own production facility in Brazil.
Technical specifications
- Output power: 1 × 1200 W RMS @ 2 Ω / 1 × 792 W RMS @ 4 Ω
- Operating voltage: 9–16 V
- Current consumption (music): 52 A @ 2 Ω
- Recommended fuse: 70 A
- Recommended battery: 70 Ah
- Power cable: 16 mm² (5 AWG)
- Speaker cable: 2 × 2.5 mm² @ 2 Ω
- Efficiency: 91%
- Damping factor: 2000
- Frequency response: 5 Hz–25 kHz
- SNR: 95 dB
- Input sensitivity: 0.2–2 V
- Subsonic filter: 5–80 Hz
- Low Pass Filter (LPF): 50 Hz–1 kHz
- Bass Boost: 0–12 dB @ 50 Hz
- Dimensions (L × W × H): 180 × 136 × 55 mm
- Weight: 1.12 kg
Do not connect the amplifier below its rated load!
