DD Audio SL610 D4 - Shallow Mount Subwoofer
The Redline SL-610 is a very powerful shallow mount subwoofer equipped with excellent sound quality.
A good solution if the subwoofer enclosure needs to be/is desired to be very shallow. The driver is only 10.1cm deep, so it offers plenty of installation options compared to a traditional subwoofer.
SL series 10" subwoofers work in enclosures as small as 14L (sealed/ported).
Features
- 10" shallow mount subwoofer
- Mounting depth only 10.1cm
- EROM surround
- 2.5" high-temperature voice coil
- Double spider system
- Triple-layer flat cone
- 72oz magnet
- Voice coil ventilation in the backplate
- DD cast aluminum frame
- Dual 4Ω voice coil
Technical specifications
- Size: 10"
- Impedance: 2x4Ω (dual voice coil)
- Power handling RMS: 300-600W
- Power handling Peak: 1200W
- Voice coil: 2.5"
- Fs: 29Hz
- Qms: 6.878
- Qes: 0.393
- Qts: 0.372
- Vas: 26.769 liters
- Xmech: 40mm
- Xmax: 14.5mm
- Frame outer diameter: 26.92cm
- Frame outer diameter with gasket: 27.4cm
- Mounting hole diameter: 23.5cm (235mm)
- Mounting depth: 10.1cm (101mm)
- Motor diameter: 16.51cm
- Motor depth: 3.81cm
- Driver displacement: 0.84 liters
- Weight: 7 kg
Enclosure recommendations
- Sealed enclosure: 14-28 liters
- Ported enclosure: 14-35 liters
